Switch Gear
Characteristic
Z F4B-126 is type of three busbars in one tank,the bay width is 800mm.The bay installation dimension is 1000(width)*5000(length)*3000(height).It has the characteristic:high insulation level,big allowance of insulation,and it is the first product that the full capacity breaking current reaches to 50KA.
Parameter
| Type | ZF4B-126 |
| Rated voltage (kV) | 126/145 |
| Rated current (A) | 1250～3150 |
| Rated short circuit breaking current (kA) | 40 |
| Rated short circuit making current (kA) | 100 |
| Mechanical life (times) | 10000 |
| Bay width (mm) | 800 |
| Operating device | With spring operation device |
| Note | Three phases in one tank |
